Before installing or upgrading ArcGIS Pro on a virtual or physical machine, make sure your system meets the minimum requirements to run it. Also, learn what resources are recommended to get the best performance.
Check your computer's ability to run ArcGIS Pro 2.5.
Supported operating systems
ArcGIS Pro is supported on the operating systems listed below, given the operating system is also currently supported by its provider for general or public use. Prior and future updates or service packs on these operating systems are supported unless otherwise stated.
| Operating system | Latest update or service pack tested |
|---|---|
Windows 10 Home, Pro, and Enterprise (64 bit) | November 2019 update |
Windows 8.1 Pro and Enterprise (64 bit) | November 2019 update |
Windows Server 2019 Standard and Datacenter (64 bit) | November 2019 update |
Windows Server 2016 Standard and Datacenter (64 bit) | November 2019 update |
Windows Server 2012 R2 Standard and Datacenter (64 bit) | November 2019 update |
Windows Server 2012 Standard and Datacenter (64 bit) | November 2019 update |
Here, you will find the historical usage of CPU, Memory and Peak concurrent session count on the specific machine. Time ranges can be selected to view the historical resource Utilization. We support 2 hours, 24 hours, 7 days, 1 month and 1 year periods. Three graphs show the historical trend of each parameter – CPU, Memory and Session Count. HIGH memory usage by Citrix Monitor Service on our Delivery Controllers to where it is affecting Director. Solution This is fixed in Upgrade the Controller patch 7.1.3.
Hardware requirements
| Item | Supported and recommended |
|---|---|
CPU speed | Minimum: 2 cores, hyperthreaded* |
Recommended: 4 cores | |
Optimal: 10 cores | |
Platform | x64 with SSE2 extensions |
Memory/RAM | Minimum: 4 GB |
Recommended: 8 GB | |
Optimal: 16 GB or more | |
Display properties | 24-bit color depth Also see Video/Graphics adapter requirements below. |
Screen resolution | 1024x768 or higher at normal size |
Visualization cache | The temporary visualization cache for ArcGIS Pro can consume up to 32 GB of space, if available, in the user-selected location. By default, the visualization cache is written to the user profile.** |
Storage | Minimum: 32 GB of free space |
Recommended: 32 GB or more of free space on a solid-state drive (SSD) |
*Hyperthreaded CPUs typically feature two threads per core. A hyperthreaded 2-core CPU will have four threads available for processing, while a hyperthreaded 6-core CPU will have 12 threads available for processing.
**The cache is written by default to the user profile’s Local subfolder, so it does not roam with the user profile if roaming profiles are enabled by your system administrator.
Video/Graphics adapter requirements
Refer to the video/graphics adapter requirements below for information on how to achieve the best graphics performance.
| Item | Supported and recommended |
|---|---|
DirectX* | Minimum: DirectX 11, feature level 11.0, Shader Model 5.0 |
Recommended: DirectX 11, feature level 11.0, Shader Model 5.0 | |
OpenGL* | Minimum: OpenGL 4.3 with the EXT_texture_compression_s3tc extension |
Recommended: OpenGL 4.5 with the ARB_shader_draw_parameters, EXT_swap_control, EXT_texture_compression_s3tc, and EXT_texture_filter_anisotropic extensions | |
Dedicated (not shared) graphics memory** | Recommended: 4 GB or more |
*ArcGIS Pro will automatically use OpenGL if DirectX requirements are not met. You can manually change to OpenGL if you suspect an issue with your driver.
**If you're using a notebook computer with an integrated GPU, consider increasing the system RAM to compensate for the usage of shared memory.
Software requirements
The following software must be installed before installing ArcGIS Pro:
| Software | Requirement |
|---|---|
.NET Framework | Microsoft .NET Framework 4.8 or later |
Browser | Microsoft Internet Explorer 11 |
Three license types are available for ArcGIS Pro 2.5. Depending on the type you use, you may need additional software or access to ArcGIS Online:
- Named User license—ArcGIS Pro is licensed through an organizational account on ArcGIS Online or ArcGIS Enterprise. If the license is through ArcGIS Online (the default option), licensing software is not required because ArcGIS Online is a cloud-based service provided by Esri.
If the license is through ArcGIS Enterprise, you must install one of the versions indicated in the table below, along with a corresponding supported version of ArcGIS License Manager.
ArcGIS Enterprise ArcGIS License Manager 10.8
2019.2
10.7.1
2019.2
10.7
2019.2
10.6.1
2019.2
10.6
2019.2
- Concurrent Use license—ArcGIS License Manager 2019.2 or later is required to manage ArcGIS Pro 2.5 licenses.
- Single Use license—No additional software is required for licensing.
SDK requirements
The minimum requirements to create add-ins using the ArcGIS Pro SDK for .NET are described in the SDK GitHub repository.
Virtualization
ArcGIS Pro is supported in various on-premises and cloud environments as shown in the four tables below.
In all environments, a GPU that is compatible with your virtualization platform is recommended for the best user experience.
Note:
The Virtualization section of the help provides additional information about setting up virtualization environments for ArcGIS Pro.
| On-premises virtual desktop infrastructure (VDI) | Notes |
|---|---|
Citrix XenDesktop 7.6 LTSR CU7 | Use the latest Citrix and NVIDIA drivers. Refer to the Citrix and NVIDIA GRID websites for the most current driver versions. |
Citrix XenDesktop 7.15 LTSR CU4
| |
Citrix Virtual Apps and Desktop 7 1906 | |
Microsoft Hyper-V Server 2012 R2 | Microsoft VDI certified with RemoteFX vGPU Windows Device Driver Model (WDDM) 1.2. |
Microsoft Hyper-V Server 2016 | |
Microsoft Hyper-V Server 2019 | Use Discrete Device Assignment (DDA) to pass through the GPU. Download video jurus tunggal baku. |
VMware vSphere 6.5 | Use VMware Horizon View 7.x and later only. Use the latest VMware and NVIDIA drivers. Refer to the VMware and NVIDIA GRID websites for the most current driver versions. |
VMware vSphere 6.7 |
| On-premises application streaming and virtualizing | Notes |
|---|---|
Citrix XenApp 7.6 LTSR CU7 | Hosted OS:
|
Citrix XenApp 7.15 LTSR CU4 | Windows Server 2016 |
Citrix Virtual Apps and Desktop 7 1906 | Windows Server 2016 |
Note:
- ArcGIS Pro with Citrix XenApp is strongly discouraged because of poor XenApp session/server density. This is based on testing using Windows Server 2012 R2 and 2016.
ArcGIS Pro provides a nominal level of functionality and performance in the following environments:
- Microsoft App-V
- VMware App Volumes
| Cloud virtual desktop infrastructure (VDI) | Notes |
|---|---|
Amazon WorkSpaces Graphics Bundle | |
Azure Nx-Series VMs | Nx6 is recommended because it includes one GPU, and ArcGIS Pro currently doesn't need more than one GPU. Windows 10 client RDP is adequate for most workloads; Teradici technology may be helpful for demanding workloads. Note:When using Spatial Analyst tools or machine learning capabilities that leverage GPU, more than one GPU may be helpful to support visualization and computation. Consider this option if running Spatial Analyst tools or machine learning capabilities and the display becomes jerky. Here are the current lists of Spatial Analyst tools and machine learning capabilities that utilize the GPU for computation. |
| Cloud application streaming and virtualizing | Notes |
|---|---|
AWS AppStream | |
Azure Citrix XenApp |
System requirements for recent versions of ArcGIS Pro
- ArcGIS Pro 2.2 system requirements - Retirement date: July 1, 2021
